Mains input via P-Con (blue), mounting version power supply cord with safety plug
Cable construction:
3 x 1.5 mm² H05VV-F
Power output:
P-Con (gray), mounting version
Fuse:
5 x 20 mm, T 2 A fuse replaceable
Lamp type:
LED lamp
LED type:
1 x 120 W COB (chip-on-board) 4in1 QCL RGBL (homogenous color mix)
Flash rate:
1 - 20 Hz
Equipment:
Zoom manual
DMX channels:
1; 2; 4; 6; 16
DMX input:
5-pin XLR (M) mounting version 3-pin XLR (M) mounting version
DMX output:
5-pin XLR (F) mounting version 3-pin XLR (F) mounting version
Cooling:
1 x temperature-controlled fan
Control:
DMX; RDM; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); W-DMX by wireless solution via USB (optional); rotary dial for brightness; stand-alone
Fixtures available for:
GDTF (GrandMA3); Light Captain; Light´J
Projection:
Flicker-free
DMX features:
RDM For bidirectional communication over the DMX line
DMX fail mode:
Hold; blackout; manual
Beam angle:
3° - 48°
Beam angle (1/2 peak):
3 - 26°
Beam angle (1/10 peak):
14 - 48°
Color temperature:
2400K - 8500K adjustable
Lamp life:
30000 h
Housing color:
Black
Attachment system:
Mounting bracket
Display type:
Monochrome LCD display
USB port:
Type A
Diameter mounting holes:
3 x Ø10mm
Use of brands:
Built with SEETRONIC connector
Material:
Aluminum
Dimensions:
Length: 35.0 cm Width: 31.5 cm Height: 39.5 cm
Weight:
7.10 kg
Noise classification:
Class 1 (very slight noise, suitable for noise-sensitive environments) depending on mode used
