Additional frost filter provides a wide, soft and homogeneous light
Positioning within 540° PAN, 230° TILT
Auto position correction (feedback)
Exact positioning (16 bit resolution)
Exact 16 bit resolution at zoom, focus
Prism 16-fold; prism 8-fold rotating; prism 16-fold rotating; gobo wheel with static gobos; gobo wheel with rotating gobos; focus motor-driven; zoom motor driven; frost filter; Dimmer
Color animations; patterns
Beam effect; spot effect; wash effect
Color wheel with 13 dichroic filters plus open rainbow effect with adjustable speed in both directions; half colors selectable, Rainbow effect with adjustable speed in both directions
Gobo wheel with rotating gobos, 7 gobos and open shake effect
Slot-in gobo system for easy gobo replacement
Gobos changeable
Gobo wheel with static gobos, 11 gobos and open shake effect
Gobo wheel with static gobos, 5 gobos and open shake effect
Integrated show programs
The device is cooled by cooling fan
Control via stand-alone; DMX; sound to light via microphone; master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Preprogrammed in Light Captain
With a beam angle of 4° - 35°
Multicolor LCD display, with battery buffering for easy controlling
Mains input and output for power linking up to 4 units
OSRAM bulb included
For application areas such as: Clubs/dancing school; stage; rental
Application possibility: Standing; suspended
1 x moving light, 1 x user manual, 1 x power cord, 2 x omega bracket
Power supply:
100-240 V AC, 50/60 Hz
Power consumption:
490 W
IP classification:
IP20
Protection class:
Protection class I
Power connection:
Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:
P-Con (gray), mounting version
Fuse:
5 x 20 mm, T 8 A
Lamp type:
Discharge lamp
Max. TILT movement:
230° exact positioning (16 bit resolution) auto position correction (feedback)
Max. PAN movement:
540° exact positioning (16 bit resolution) auto position correction (feedback)
Flash rate:
1 - 18 Hz
Equipment:
Prism 16-fold; prism 8-fold rotating; prism 16-fold rotating; gobo wheel with static gobos; gobo wheel with rotating gobos; focus motor-driven; zoom motor driven; frost filter; Dimmer
Color generation:
Color wheel with 13 dichroic filters plus open Rainbow effect with adjustable speed in both directions; half colors selectable, Rainbow effect with adjustable speed in both directions
Gobos:
Gobo wheel with rotating gobos, 7 gobos and open Shake effect Outside diameter 22.5mm Image diameter 12mm Slot-in gobo system for easy gobo replacement Gobos changeable Gobo wheel with static gobos, 11 gobos and open Shake effect Gobo wheel with static gobos, 5 gobos and open Shake effect
DMX channels:
22; 26
DMX input:
3-pin XLR (M) mounting version
DMX output:
3-pin XLR (F) mounting version
Cooling:
Cooling fan
Control:
Stand-alone; DMX; sound to light via microphone; master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Preprogrammed in:
Light Captain
Beam angle:
4° - 35°
Beam angle (1/2 peak):
Spot 4 - 35°
Beam angle (1/10 peak):
Spot 4 - 35°
Housing color:
Black
Display type:
Multicolor LCD display battery buffering
Use of brands:
OSRAM bulb included
Dimensions:
Width: 39.5 cm Depth: 30.5 cm Height: 63.0 cm
Weight:
22.70 kg
Noise classification:
Class 3 (clearly perceptible sounds)
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
