Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Power output:
1 x P-Con (gray), mounting version Bypass 2 x IEC connector (F) mounting version fused / 5A
Device fuse:
5 x 20 mm, T 1.6 A fuse replaceable
Power output fuse per channel:
5 x 20 mm, T 5 A fuse replaceable
Lamp type:
LED lamp
LED type:
12 x 10 W SMD 5050 4in1 QCL RGB/WW (homogenous color mix)
Flash rate:
0.3 - 20 Hz
DMX channels:
3; 4; 6; 8; 16; 18; 20
DMX input:
1 x 3-pin XLR (M) mounting version
DMX output:
1 x 3-pin XLR (F) mounting version Bypass
Cooling:
Passive convection cooling
Control:
Stand-alone; sound to light via microphone; master/slave function; rotary dial for brightness; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); AirW; wireless Master/slave function; wireless remote control; wireless footswitch (optional)
Projection:
Flicker-free
Range:
AirW: range up to 70m with line-of-sight
Carrier frequency:
2.4 GHz
Modulation:
GFSK
DMX fail mode:
Blackout; hold; full on; auto
Beam angle:
12°
Beam angle (1/2 peak):
Spot 12°
Beam angle (1/10 peak):
Spot 25°
Color temperature:
2880K
Color rendering index (CRI):
83 Ra
Housing color:
Black matte
Attachment system:
Tube: 1x Ø 35mm 2x mounting bracket
Display type:
1 x monochrome 4 digit 7-segment LED display
USB port:
1 x type A
Diameter mounting holes:
2 x Ø8mm
Dimensions:
Length: 104 cm Width: 5.5 cm Height: 24.9 cm
Weight:
7.40 kg
Noise classification:
Class 0 (no noise at all)
Power cord
Cable construction:
3 x 1.0 mm² H05VV-F
Cable length:
Approx. 3 m
Remote control
Battery:
1 x 12 V 23AE alkaline manganese included
Range:
Wireless remote control: range up to 30m with line-of-sight
Carrier frequency:
433.92 MHz
Bar
Material:
Metal, painted
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
