Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided)
Cable construction:
3 x 1.0 mm² H05VV-F
Cable length:
3 m
Power output:
1 x P-Con (gray), mounting version Bypass 2 x IEC connector (F) mounting version fused
Device fuse:
5 x 20 mm, T 5 A fuse replaceable
Power output fuse per channel:
5 x 20 mm, T 5 A fuse replaceable
Lamp type:
LED lamp
LED type:
28 x 12 W SMD 5050 6in1 HCL RGBWA/UV (homogenous color mix)
Flash rate:
0.3 - 20 Hz
DMX channels:
2; 4; 6; 10; 24; 28; 32; 34
DMX input:
1 x 3-pin XLR (M) mounting version 1 x USB, type A
DMX output:
1 x 3-pin XLR (F) mounting version
Cooling:
Passive convection cooling
Control:
Stand-alone; sound to light via microphone; master/slave function; rotary dial for brightness; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); AirW; wireless Master/slave function; wireless remote control; wireless footswitch (optional)
Projection:
Flicker-free
Range:
Wireless remote control: range up to 30m in the open air AirW: range up to 70m with line-of-sight
Carrier frequency:
2.4 GHz
Modulation:
GFSK
DMX fail mode:
Blackout; hold; full on; auto
Beam angle:
15°
Beam angle (1/2 peak):
15° multicolor
Beam angle (1/10 peak):
Spot 30°
Color temperature:
5700K
Housing color:
Black matte
Attachment system:
Pivot: 1x TV spigot Ø 28mm 2x omega bracket
Display type:
1 x monochrome 4 digit 7-segment LED display
USB port:
1 x type A
Material:
Metal, 1 mm, painted
Dimensions:
Length: 107.5 cm Depth: 5.5 cm Height: 28.7 cm
Weight:
11.30 kg
Noise classification:
Class 0 (no noise at all)
Remote control
Battery:
1 x 12 V 23AE alkaline manganese included
Carrier frequency:
433.92 MHz
Legal specifications
Special product:
Not designed for household room illumination
Intended use:
Show effect lighting
