3 microphone inputs (6.3 mm jack, unbal.) with separate level controls
Microphone input 3 with adjustable priority circuit
3 line inputs (stereo RCA) with separate level controls
1 line output (stereo RCA)
Chime, switchable
Treble and bass control for the output signal
7-digit LED level meter
Master control for the output signal
(19) 48.3 cm rack installation 2 U
The device is cooled by cooling fan
For application areas such as: Installation; restaurants, bars and hotels; sports centres/gyms
1 x amplifier, 1 x user manual
Power supply:
230 V AC, 50 Hz
Power consumption:
500.00 W
Output power:
250 W RMS
Power connection:
Fixed power supply cord with safety plug
Frequency range:
80 - 14000 Hz
S/N ratio:
>75 dB microphone >85 dB line
Cooling:
Cooling fan
Impedance:
4-16 ohms; public address systems 100V; Public address systems 70V
Circuitry:
Class AB
Controls:
Power on/off transient; Overvoltage; short-circuit
Connections:
Input: microphone via 3 x 6.3 mm plug (unbal.) Input: line via 3 x stereo RCA 0.3 V Output: line via 1 x stereo RCA 0.3 V Output: speaker via screw terminal
