For application areas such as: Installation; mobile use; mobile djs / entertainer
1 x device, 1 x external mains adapter, 4 x foot, 1 x user manual
Power supply:
230 V AC, 50 Hz 12V 150 mA
Pin configuration:
Inside - / outside +
Protection class:
Protection class III
Power connection:
Mains input via coaxial power connector (M) mounting version power supply cord with AC adapter (provided)
Number of channels:
1
Frequency range:
25 - 16000 Hz
S/N ratio:
>75 dB
THD:
<0.01 % at 1 kHz
Phantom power:
Or 30 V DC
Impedance:
Input: 10 kOhm
Gain:
50 dB
Control elements:
Level control, phantom power switch
Connections:
Input: microphone via 1 x 3-pin XLR (F) mounting version Input: microphone via 1 x 6.3 mm plug (unbal.) Output: line via 1 x 3-pin XLR (M) mounting version Output: line via 1 x 6.3 mm plug (unbal.)
