Art-Net interface for output of 8 universes on XLR Art-Net Interface zur Ausgabe von 8 DMX-Universen auf XLR - Parallel DMX input possible (1024 channels)
- 8 optically isolated XLR plugs (3-pin) for DMX output
- 2 XLR jacks (3-pin) for DMX input
- Variable data routing capabilities for all DMX outputs
- User-friendly configuration directly at the front panel via 4 operating buttons and alphanumeric LCD screen (2 x 16 characters)
- LED indication for functions
- Splitter operation possible
- Can transmit up to 4096 DMX channels
- Control via Art-Net
- The device can be connected via RJ-45 (F) mounting version to the PC
- (19) 48.3 cm rack installation
- 1 x device, 1 x user manual, 1 x power cord
| Power supply: | 100-240 V AC, 50/60 Hz | | Power consumption: | 5 W | | Power connection: | Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) | | DMX channels: | Output 4096 | | DMX input: | 2 x 3-pin XLR (M) mounting version | | DMX output: | 8 x 3-pin XLR (F) mounting version | | Network connection: | Protocol: Art-Net 3 via 2x RJ-45 (F) mounting version | | Control: | Art-Net | | Connections: | 2 x RJ-45 E-Con (F) mounting version | | PC connect: | Via RJ-45 (F) mounting version | | Housing design: | (19") 48.3 cm rack installation | | Dimensions: | Width: 48.3 cm Depth: 17.5 cm Height: 4.45 cm | | Weight: | 2.20 kg |

|
